Load capacity |
250 kg |
Lifting speed at 50 Hz |
16m / min |
Operating voltage |
400V (3ph) / 230V (1ph) 50 Hz - 24Vdc |
Protection Class |
IP 55 DIN 40050 |
Motor power at 50 Hz |
0.75 kW |
FEM Class |
2m |
DC braking system |
2 brakes |
Noise level |
<67.5 dB (full load) |
Loading wheel |
5 pockets |
RUD® Load chain |
6,3x19 mm |
Number of chains |
1 |
Chain weight |
0.86 kg / m |
Weight of the body |
35 kg |
Type of control |
24V Low voltage control |
Type of connector |
400V EEC 16A - 3P + PE / 230 EEC 16A - 2P + PE XLR3/XLR5 connector |
Climbing use |
permitted |
Safety factor |
10:1 |
Load cell |
Included |
Stromag ® Limit Switch with 4 switches |
Included |
Encoder |
Optional |
Inverter |
Included |
